Basic Configuration
| Total weight | 85000 kg |
| Standard bucket capacity | 5m³ |
| Rated power | 375/1800 kW/rpm |
Basic Parameters
FK800-9
| Basic parameters | |
| Total Weight | 85000 kg |
| Standard bucket capacity | 5 m³ |
| Performance parameter | |
| Engine | Cummins |
| Engine rated power | 375/1800 kW/rpm |
| Fuel tank volume | 1250 L |
| Traveling speed (high/low) | 4.6/2.8 km/h |
| Rotation speed | 7.1 r/min |
| Climbing capacity | 35/70% |
| Grounding specific pressure | 489 kpa |
| Job parameters | |
| Counterweight clearance from the ground | 1525 mm |
| Tail turning radius | 5090 mm |
| Track ground length | 4730 mm |
| Track length | 5975 mm |
| Track gauge | 2760 mm |
| Track width | 3400/4000 mm |
| Track plate width | |
| Transport size | |
| Overall length (transport state) | 18200 mm（A） |
| Overall width (transport state) | 3560 mm（B） |
| Overall height (transport state) | 3515 mm（C） |
| Other parameters | |
| Turntable width(mm) | 3830 |
| Bucket bar length(mm) | 10 |
| Length of moving arm(mm) | 6 |
| Bucket digging force (kN) ISO | 341 |
| Bucket digging force (kN) ISO | 307 |
| Hydraulic pump model | K3V280 |
| Maximum flow rate | 436×2 |
| Working pressure | 31.4(32.3) |
